AO3401A AOS MOSFET P-CH 30V 4A SOT23-3L
AO3401A Images
AO3401A Images
  • Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3
  • Description: MOSFET P-CH 30V 4A SOT23-3L
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
AO3401A Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
AO3401A Specifications:
  • MfrPart.: AO3401A
  • Mfr: Alpha & Omega Semiconductor Inc. (AOS)
  • Description: MOSFET P-CH 30V 4A SOT23-3L
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Not For New Designs
  • FETType: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 4A (Ta)
  • DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 10V
  • RdsOn(Max)@IdVgs: 44mOhm @ 4.3A, 10V
  • Vgs(th)(Max)@Id: 1.3V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 12.2 nC @ 4.5 V
  • Vgs(Max): ±12V
  • InputCapacitance(Ciss)(Max)@Vds: 1200 pF @ 15 V
  • FETFeature: -
  • PowerDissipation(Max): 1.4W (Ta)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: SOT-23-3
  • AO3401A AOS, MOSFET P-CH 30V 4A SOT23-3L, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AO3401A, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
