AO3409 AOS MOSFET P-CH 30V 2.6A SOT23-3L
AO3409 Images
AO3409 Images
  • Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3
  • Description: MOSFET P-CH 30V 2.6A SOT23-3L
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
AO3409 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
AO3409 Specifications:
  • MfrPart.: AO3409
  • Mfr: Alpha & Omega Semiconductor Inc. (AOS)
  • Description: MOSFET P-CH 30V 2.6A SOT23-3L
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Not For New Designs
  • FETType: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 2.6A (Ta)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 130mOhm @ 2.6A, 10V
  • Vgs(th)(Max)@Id: 3V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 9 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 370 pF @ 15 V
  • FETFeature: -
  • PowerDissipation(Max): 1.4W (Ta)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: SOT-23-3
  • AO3409 AOS, MOSFET P-CH 30V 2.6A SOT23-3L, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AO3409, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
