AO4296 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 100V 13.5A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AO4296 Specifications:
- MfrPart.: AO4296
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CH 100V 13.5A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: AlphaSGT™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 13.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 8.3mOhm @ 13.5A, 10V
- Vgs(th)(Max)@Id: 2.3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 60 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3130 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- AO4296 AOS, MOSFET N-CH 100V 13.5A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AO4296, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
