AOD2146 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252
- Description: 40V N-CHANNEL ALPHASGT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AOD2146 Specifications:
- MfrPart.: AOD2146
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: 40V N-CHANNEL ALPHASGT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: AlphaSGT™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 34.5A (Ta), 54A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.1mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 70 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3830 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 6.2W (Ta), 100W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252
- AOD2146 AOS, 40V N-CHANNEL ALPHASGT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AOD2146, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
