AOD409 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (DPAK)
- Description: MOSFET P-CH 60V 26A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AOD409 Specifications:
- MfrPart.: AOD409
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET P-CH 60V 26A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 26A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 40mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 54 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3600 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 60W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (DPAK)
- AOD409 AOS, MOSFET P-CH 60V 26A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AOD409, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
