AOD4120L Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (DPAK)
- Description: MOSFET N-CH 20V 25A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AOD4120L Specifications:
- MfrPart.: AOD4120L
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CH 20V 25A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 25A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 10V
- RdsOn(Max)@IdVgs: 18mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18 nC @ 10 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 900 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 33W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (DPAK)
- AOD4120L AOS, MOSFET N-CH 20V 25A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
