AOD514 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (DPAK)
- Description: MOSFET N-CH 30V 17A/46A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AOD514 Specifications:
- MfrPart.: AOD514
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CH 30V 17A/46A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 17A (Ta), 46A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6.5mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.6V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22.5 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 951 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 50W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (DPAK)
- AOD514 AOS, MOSFET N-CH 30V 17A/46A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AOD514, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
