AOD9N50 AOS MOSFET N-CH 500V 9A TO252
AOD9N50 Images
AOD9N50 Images
  • Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (DPAK)
  • Description: MOSFET N-CH 500V 9A TO252
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
AOD9N50 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
AOD9N50 Specifications:
  • MfrPart.: AOD9N50
  • Mfr: Alpha & Omega Semiconductor Inc. (AOS)
  • Description: MOSFET N-CH 500V 9A TO252
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 500 V
  • Current-ContinuousDrain(Id)@25°C: 9A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 860mOhm @ 4.5A, 10V
  • Vgs(th)(Max)@Id: 4.5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 24 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 1160 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 178W (Tc)
  • OperatingTemperature: -50°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: TO-252 (DPAK)
  • AOD9N50 AOS, MOSFET N-CH 500V 9A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AOD9N50, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
