AON6156 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN (5x6)
- Description: MOSFET N-CHANNEL 45V 100A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AON6156 Specifications:
- MfrPart.: AON6156
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CHANNEL 45V 100A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 45 V
- Current-ContinuousDrain(Id)@25°C: 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.6mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 70 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3975 pF @ 22.5 V
- FETFeature: -
- PowerDissipation(Max): 78W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFN (5x6)
- AON6156 AOS, MOSFET N-CHANNEL 45V 100A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AON6156, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
