AON6780 AOS MOSFET N-CH 30V 30A/85A 8DFN
AON6780 Images
AON6780 Images
  • Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN (5x6)
  • Description: MOSFET N-CH 30V 30A/85A 8DFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
AON6780 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
AON6780 Specifications:
  • MfrPart.: AON6780
  • Mfr: Alpha & Omega Semiconductor Inc. (AOS)
  • Description: MOSFET N-CH 30V 30A/85A 8DFN
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: SRFET™
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 30A (Ta), 85A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 1.7mOhm @ 20A, 10V
  • Vgs(th)(Max)@Id: 2V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 76 nC @ 10 V
  • Vgs(Max): ±12V
  • InputCapacitance(Ciss)(Max)@Vds: 9600 pF @ 15 V
  • FETFeature: Schottky Diode (Body)
  • PowerDissipation(Max): 2.5W (Ta), 83W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: 8-DFN (5x6)
  • AON6780 AOS, MOSFET N-CH 30V 30A/85A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AON6780, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
