AON7292 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN-EP (3.3x3.3)
- Description: MOSFET N-CH 100V 9A/23A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AON7292 Specifications:
- MfrPart.: AON7292
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CH 100V 9A/23A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: AlphaMOS
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta), 23A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 24mOhm @ 9A, 10V
- Vgs(th)(Max)@Id: 2.6V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 25 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1170 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 4.1W (Ta), 28W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFN-EP (3.3x3.3)
- AON7292 AOS, MOSFET N-CH 100V 9A/23A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
