AON7516 Images
- Manufacturer: AOS (Alpha and Omega Semiconductor Limited)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN (3x3)
- Description: MOSFET N-CH 30V 20A/30A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AON7516 Specifications:
- MfrPart.: AON7516
- Mfr: Alpha & Omega Semiconductor Inc. (AOS)
- Description: MOSFET N-CH 30V 20A/30A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 20A (Ta), 30A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 4.5mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 33 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1229 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta), 25W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFN (3x3)
- AON7516 AOS, MOSFET N-CH 30V 20A/30A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AON7516, AOS authentic parts in stock from AOS authorized distributors, order today, can ship immediately.
